Configure inputs to begin
Set options on the left, then click “Submit job”.
Genie 3 is an all-atom SE(3)-equivariant diffusion model for protein design. Unlike backbone-only generators that produce only Cα traces, it models every heavy atom during generation, so output structures are ready for visualization, sequence inversion, and downstream validation without an extra full-atom reconstruction step.
The model supports three design tasks from a single checkpoint:
Genie 3 is developed by the AQLaboratory. The implementation on ProteinIQ runs the official generation pipeline and returns each sampled structure as a PDB file.
ProteinIQ hosts Genie 3 on GPU infrastructure and surfaces the three design modes through one form. Choose a mode, set the length or motif constraints, and request up to 20 samples. The job returns PDB files for every generated structure plus a file list, with no local installation of the model, sampling code, or evaluation dependencies.
The required input depends on the selected design mode.
| Mode | Required input | Accepted formats |
|---|---|---|
| Unconditional | None | Only length settings |
| Motif scaffolding | One motif structure | .pdb, .ent, or RCSB PDB ID |
| Binder design | One target structure | .pdb, .ent, or RCSB PDB ID |
For motif scaffolding and binder design, the uploaded structure should be clean: one conformer per residue, no alternative locations, and residue numbering that matches the segment or hotspot specification. RCSB fetches retrieve the PDB file directly.
| Setting | Type | Range / values | Default | Description |
|---|---|---|---|---|
design_mode | Select | unconditional, motif_scaffolding, binder_design | unconditional | Which design task to run. |
n_sample | Slider | 1–20 | 5 | Number of independent structures to generate. More samples increase cost and runtime. |
n_sample_step | Slider | 20–200 | 100 | Number of diffusion denoising steps. 100 is the Genie 3 default. |
predict_sequence | Switch | On / off | Off | When enabled, Genie 3 also predicts an amino acid sequence for each generated structure. |
| Setting | Range | Default | Description |
|---|---|---|---|
direction_scale_unconditional | 0–2 | 0.8 | DDIM guidance scale for unconditional generation. |
min_length | 20–256 | 50 | Minimum total number of residues. |
max_length | 20–256 | 50 | Maximum total number of residues. |
length_step | 1–236 | 50 | Step size for sampling lengths between min_length and max_length. |
If min_length equals max_length, every sample has the same length. If they differ, Genie 3 samples lengths across the range and generates n_sample structures per sampled length.
| Setting | Range | Default | Description |
|---|---|---|---|
motif_segments | Text | A1-10 | Fixed residue ranges in ChainStart-End format. Multiple segments are separated by commas. |
direction_scale_motif | 0–2 | 0.1 | DDIM guidance scale for motif scaffolding. |
scaffold_flank_min | 0–100 | 5 | Minimum residues generated before and after the motif. |
scaffold_flank_max | 0–100 | 15 | Maximum residues generated before and after the motif. |
The motif structure must contain a single protein chain. The total design length includes both the fixed motif residues and every generated flanking scaffold segment. The combined length must stay within the 256-residue limit.
| Setting | Range | Default | Description |
|---|---|---|---|
target_hotspots | Text | empty | Target interface residues in ChainResidue format, for example A65,A74. |
direction_scale_binder | 0–2 | 0.0 | DDIM guidance scale for binder design. |
binder_length_min | 20–256 | 40 | Minimum length of the designed binder. |
binder_length_max | 20–256 | 80 | Maximum length of the designed binder. |
Hotspot residues define where the binder should contact the target. They must be present in the uploaded target structure and use the same chain IDs and residue numbers.
Genie 3 returns one PDB file per generated structure. ProteinIQ renders the structures in an interactive 3D viewer and lists all files for download.
| Output | Description |
|---|---|
| PDB files | One structure per sample. Atom records include all heavy atoms generated by the diffusion model. |
| File list | Spreadsheet-like list of generated files with metadata for each sample. |
If predict_sequence is enabled, residue names in the generated PDB files reflect the predicted amino acid sequence. The returned structures are not energy-minimized or folded by a structure predictor by default.
Genie 3 treats protein design as a diffusion process over 3D atomic coordinates. During training, the model learns to reverse a noise-corruption process that gradually perturbs real protein structures. At inference time, it starts from random coordinates and iteratively denoises them into physically plausible protein geometries.
SE(3)-equivariance means the model's predictions transform consistently with rotations and translations of the input. If the input structure is rotated, the output rotates by the same amount without changing the internal geometry. This removes the need for data augmentation and lets the model learn geometric relationships in a coordinate-independent way.
Modeling all atoms, not just the backbone, matters most for design tasks where side-chain packing determines success. Binder interfaces, motif scaffolding constraints, and hydrogen-bond networks all depend on accurate heavy-atom geometry.
The mode-specific direction scale controls classifier-free guidance strength during DDIM sampling. Genie 3's example configurations use 0.8 for unconditional short proteins, 0.1 for motif scaffolding, and 0.0 for binder design. Higher values follow the model direction more strongly; lower values allow more diversity.
n_sample_step sets the number of denoising iterations. 100 steps match the Genie 3 default and balance quality with runtime. Fewer steps run faster but may leave residual noise. More steps refine local geometry at increased cost.
Generated structures should be treated as design candidates, not final experimental structures. The diffusion model produces geometrically plausible backbones and side-chain conformations, but it does not guarantee foldability, stability, or binding affinity.
A practical validation workflow on ProteinIQ looks like this:
Common warning signs include:
Genie 3 is a generative structure model. It is most useful when the goal is to explore new protein geometries rather than evaluate an existing sequence or complex.
| Task | Recommended tool | Why |
|---|---|---|
| Generate novel protein backbones | Genie 3 | Direct all-atom diffusion with length control. |
| Design binders to a target surface | Genie 3 or BindCraft | Genie 3 is fast and diffusion-native; BindCraft uses AlphaFold2-guided hallucination with built-in filtering. |
| Scaffolding a functional motif | Genie 3 | Holds fixed segments and redesigns flanking scaffold regions. |
| Redesign sequence for an existing backbone | ProteinMPNN | Inverse folding is faster and more controllable than full diffusion. |
| Predict structure of an existing sequence | AlphaFold 2 or Boltz-2 | These are predictors, not generators. |
| Small-molecule docking | AutoDock Vina or DiffDock | Genie 3 does not model ligand poses. |
Both tools generate protein binders, but their philosophies differ. Genie 3 samples from a diffusion model conditioned on target hotspots and returns raw structures quickly. BindCraft runs a longer optimization loop that uses AlphaFold2-Multimer as an objective function and filters designs with interface metrics. Genie 3 is better for rapid exploration; BindCraft is better when integrated in silico filtering and relaxation are worth the extra compute.
predict_sequence are model proposals. They should be re-evaluated with an inverse-folding model or structure predictor before ordering genes.
