InChI to SMILES converts InChI (International Chemical Identifier) strings into SMILES using RDKit. InChI is a standardized, canonical chemical identifier developed by IUPAC — encoding molecular structure as a layered string such as InChI=1S/C9H8O4/.... SMILES is more widely accepted across cheminformatics tools, databases, and machine learning models. Converting InChI → SMILES is common when importing compounds from IUPAC-based databases or PubChem InChI exports into tools that expect SMILES input.
ProteinIQ handles the conversion through RDKit on the server — no local installation of any cheminformatics toolkit is needed.
Paste one InChI string per line, or use name<TAB>InChI pairs to preserve compound names in the output. Files in .txt, .csv, .tsv, or .inchi format are also accepted. Up to 10 entries are processed per job.
| Format | Example |
|---|---|
| Bare InChI | InChI=1S/C9H8O4/c1-6(10)13-8-4-2-3-7(5-8)9(11)12/h2-5H,1H3,(H,11,12) |
| Named InChI | aspirin<TAB>InChI=1S/C9H8O4/... |
| File upload | .txt, .csv, .tsv, .inchi |
Each entry produces an individual SMILES file. A combined TSV batch file is also generated listing all entries with their names and canonical SMILES strings.
| File | Contents |
|---|---|
Per-entry .smi | Canonical SMILES for the converted molecule |
batch.tsv | All entries with name and SMILES |
