StaB-ddG
v1.0.0Predict mutation effects on protein binding
StaB-ddG predicts mutation-induced changes in protein-protein binding free energy from a wild-type complex structure. It uses the final stabddg.pt checkpoint and supports single or combined substitutions, with one mutant per run or multiple mutants and complexes in a CSV.
Results are binding ΔΔG values in kcal/mol. Negative values indicate stronger predicted binding; positive values indicate weaker predicted binding. These predictions describe binding effects, not protein folding stability.
Runs cost 27 credits per minute of measured runtime. The minimum reservation is 27 credits, not a minimum final charge. Completed runs are charged in proportion to elapsed time, rounded up to a whole credit; unused reserved credits are returned. Set a spending limit before submission. Each batch job is metered separately.
| Mode | Required inputs | Formats and limits |
|---|---|---|
| One mutant | Wild-type complex, Mutation(s), and Binding partners | One .pdb file or an RCSB PDB structure; 50 MiB per uploaded file. |
| Mutation CSV | Complex structure and Mutation CSV | One or more .pdb files plus an uploaded .csv or pasted CSV text; 50 MiB per uploaded file. |
Mutation notation combines the wild-type amino acid, chain ID, position, and replacement amino acid. For example, EA63Q means E to Q at position 63 of chain A. Positions are chain-relative and start at 1; structures are not automatically renumbered. Commas join substitutions in a single combined mutant.
Binding partners are two chain groups separated by an underscore: ABC_DE means chains A, B, and C bind chains D and E. Chain IDs are individual letters or digits.
In CSV mode, the required, case-sensitive columns are #Pdb and mutation:
#Pdb,mutation
1AO7_ABC_DE,"EA63Q,QD30V,KA66A"
1C1Y_A_B,KB11MThe #Pdb value combines the PDB filename without .pdb and the two chain groups. The first row therefore requires 1AO7.pdb; the second requires 1C1Y.pdb. Quotation marks keep comma-separated substitutions in one CSV field. Additional columns are accepted.
Each structure occupies one input, with Complex structure adding more inputs. PDB filenames must be unique by basename, begin with a letter or digit, and contain only letters, digits, periods, hyphens, or underscores. Optional precomputed binding-partner files, such as 1AO7_ABC.pdb and 1AO7_DE.pdb, can accompany the complexes. Inference has a 55-minute time limit.
| Parameter | Type | Default | Description |
|---|---|---|---|
| Input mode | enum | single | single selects One mutant; csv selects Mutation CSV. |
| Mutation(s) | string | EA63Q,QD30V,KA66A | Single mode only; one substitution or a comma-separated combination. |
| Binding partners | string | ABC_DE | Single mode only; two chain groups separated by one underscore. |
| Parameter | Type | Default | Description |
|---|---|---|---|
| Monte Carlo samples | integer | 20 | At least 1; samples averaged within each trial. |
| Independent trials | integer | 1 | At least 1; produces separate pred_1 through pred_N columns. |
| Random seed | integer | 0 | Seed supplied to PyTorch inference. |
| Backbone noise (angstrom) | number | 0.1 | Backbone-noise setting in angstroms. |
| Prediction filename | string | output | Filename stem without directory separators; .csv is appended. |
| Job name | string | optional | Label used in job history. |
The Binding ΔΔG (kcal/mol) table displays the predictions. The Files tab provides individual downloads, and Download all collects the files in a ZIP.
| Download | Contents |
|---|---|
native/output.csv | Prediction table with native headers, row order, numeric precision, and CSV index; the stem follows Prediction filename. |
native/input.csv | Prepared mutation table, including additional submitted CSV columns. |
PDB files under native/ or native/pdbs/ | Wild-type complex and binding-partner structures, including supplied partner files or extracted chains. |
stab_ddg.log | Inference command and execution log. |
provenance.json | Settings, source and model identity, checksums, units, and sign convention. |
Returned PDB files represent the wild-type complex and its binding partners. StaB-ddG does not generate mutant 3D structures.
| Field | Meaning |
|---|---|
Name | Complex and chain-group identifier, displayed as Complex interface. |
Mutation | Substitutions scored together in that row, displayed as Mutation(s). |
pred_1 through pred_N | Binding ΔΔG in kcal/mol for each independent trial, averaged over that trial's Monte Carlo samples. |
Trials remain separate and are not averaged together. Values near zero indicate a small predicted change relative to wild type. The prediction columns are energy estimates, not confidence scores.
