SPRINT

(0.1.0)

Rank compound libraries with SPRINT protein and ligand co-embeddings.

Input

Protein Sequence

Compounds (SMILES)

Return top K compounds

10 credits

Output

Configure inputs to begin

Set options on the left, then click “Submit job”.

What is SPRINT?

SPRINT is a learned protein-ligand screening method that places proteins and compounds in a shared embedding space. It ranks a compound library for one protein target by cosine similarity. Unlike AutoDock Vina or GNINA, it does not generate 3D binding poses or calculate a docking energy.

This implementation runs the published SPRINT ultrafast-embed and ultrafast-topk workflow. It creates an embedding for the target, creates embeddings for the submitted compound library, and returns the compounds with the highest native CosineSimi values.

SPRINT is best used to prioritize compounds for follow-up. Its cosine similarity is a model score, not a calibrated binding probability, binding affinity, or experimental measurement.

How does SPRINT work?

SPRINT maps protein and ligand features into a shared vector space. The published Top K command normalizes those embeddings through cosine similarity and ranks larger values first.

Protein embedding

The selected checkpoint uses SaProt features. You can submit either:

A plain sequence containing the 20 standard amino acid letters. SPRINT inserts masked structure tokens for this input.
A paired SaProt sequence that alternates an uppercase amino acid with a lowercase 3Di token or # mask.

ProteinIQ does not predict a structure or generate 3Di tokens for a plain sequence. If you want the model to use known structural tokens, prepare and submit the paired SaProt representation yourself.

Compound embedding

The checkpoint uses 1024-bit Morgan fingerprints with radius 3. SPRINT projects these fingerprints into the same learned space as the protein representation.

Ranking

For each compound, SPRINT reports:

\operatorname{CosineSimi}(d,t) = \frac{\mathbf{z}_d \cdot \mathbf{z}_t} {\lVert\mathbf{z}_d\rVert \lVert\mathbf{z}_t\rVert}

Higher values rank first. ProteinIQ does not transform this value into a probability.

How to use SPRINT online

Inputs

Input	Description
Protein Sequence	Exactly one plain protein sequence or paired SaProt sequence, up to 1023 effective residues. FASTA and plain text are accepted. A FASTA header names the target-specific output files.
Compounds (SMILES)	One compound library. CSV and TSV files require a `SMILES` header and may include `id` plus additional columns. Conventional SMI files use `SMILES name`. Text input may use `name<TAB>SMILES` or one SMILES per line.

Text input example:

Text

aspirin	CC(=O)Oc1ccccc1C(=O)O
ibuprofen	CC(C)Cc1ccc(cc1)C(C)C(=O)O
caffeine	Cn1cnc2c1c(=O)n(C)c(=O)n2C

CSV input example:

csv

id,SMILES,collection
aspirin,CC(=O)Oc1ccccc1C(=O)O,reference
ethanol,CCO,reference

Additional CSV or TSV columns are preserved in the ranked output.

Settings

Setting	Description
Return top K compounds	Return 1 to 1000 compounds, default 100. If K exceeds the library size, all compounds are returned.

Results

The results table preserves the source library columns and adds the native similarity. ProteinIQ adds rank as a display field.

Column	Description
`rank`	Display rank, starting at 1 for the highest similarity
`id`	Submitted identifier or an automatically generated identifier
`SMILES`	Submitted compound structure
`CosineSimi`	Native SPRINT cosine similarity, sorted from highest to lowest
Other columns	Any additional columns from a submitted CSV or TSV library

Downloadable files include:

topk_mol_data_<query_id>.csv, the native ranked compound table
topk_mol_embeddings_<query_id>.npy, embeddings for the returned compounds
sprint_target_embeddings.npy, the target embedding
sprint_library_embeddings.npy, embeddings for the full submitted library
sprint_run.log, command output for reproducibility and troubleshooting
sprint_provenance.json, pinned source, model, and runtime identifiers

Interpreting scores

Use CosineSimi for relative ranking within a run. A larger value means the model placed that compound closer to the target in its learned embedding space. The score has no universal probability threshold and should not be interpreted as a dissociation constant, inhibition constant, or docking energy.

Screening workflow

One practical sequence is:

Filter compounds for drug-likeness using Lipinski's Rule of 5 or Molecular Descriptors
Run SPRINT to prioritize the library by cosine similarity
Assess top hits for toxicity and ADMET properties with ADMET-AI or eToxPred
Validate promising candidates with structure-based docking (DiffDock, AutoDock Vina, or GNINA)

The published Morgan featurizer substitutes a zero fingerprint when RDKit cannot parse a SMILES value. Such rows may still receive a model score. Check the run log and remove invalid structures before interpreting or advancing hits.

Limitations

SPRINT ranks learned interaction similarity. It does not return calibrated probabilities, binding affinities, poses, residue attention maps, or binding sites.
Plain protein sequences use masked structure tokens, so they do not contain the same structural information as prepared amino-acid/3Di pairs.
Performance can decrease for protein families or chemical scaffolds unlike the training data.
A single embedding cannot represent every conformational state, binding site, protonation state, tautomer, or stereochemical uncertainty.
Follow up high-ranking compounds with orthogonal computational methods and experimental assays.
