SMRTnet

What is SMRTnet?

SMRTnet predicts whether a small molecule is likely to interact with an RNA target from RNA sequence, RNA secondary structure, and a molecular SMILES string.

The method is useful when the RNA target has no reliable 3D structure. Many disease-associated RNAs fall into that category: internal ribosome entry sites, untranslated regions, onco-miRNAs, viral RNA elements, and repeat expansion transcripts can have experimentally supported secondary structure while lacking a stable tertiary model suitable for docking.

SMRTnet was developed by Fei and colleagues for small molecule-RNA interaction prediction without RNA tertiary structures. The model combines RNA and chemical language models with CNN, graph attention, and multimodal fusion layers, then reports an ensemble binding probability for each RNA-compound pair.

How to use SMRTnet online

SMRTnet can be run on ProteinIQ by entering RNA targets as tab-separated name, sequence, and dot-bracket structure rows, then entering small molecules as tab-separated name and SMILES rows. The output is a ranked table of RNA-compound pairs with binding probability scores and binary interaction calls.

Inputs

RNA input should normally use RNA alphabet conventions, with U rather than T. RNA names cannot contain spaces, other whitespace, or > because SMRTnet converts the table to FASTA before slicing it. Names are carried through to the output table, so short identifiers such as MYC_IRES, pre_miR_21, or SARS2_SL5 make results easier to review.

RNA input example

MYC_IRES	GUGGGGGCUUCGCCUCUGGCCCAGCCCUCAC	(((((((((..(((...)))..)))))))))
TAU_UTR	GCUAGCUAGCUAGCUAGCUAGCUAGCUAGCU	...(((((.......)))))............

Small molecule input example

3902-71-4	CC1=CC(=O)OC2=C1C=C3C=C(OC3=C2C)C
caffeine	CN1C=NC2=C1C(=O)N(C(=O)N2C)C
aspirin	CC(=O)OC1=CC=CC=C1C(=O)O

SMRTnet slices every RNA longer than 31 nucleotides into overlapping 31-nt windows with a step size of one. A run may contain at most 240,000 effective RNA-window/molecule pairs, calculated as the total number of 31-nt windows across all submitted RNA targets multiplied by the number of molecules. For example, one 90-nt RNA produces 60 windows and can be submitted with up to 4,000 molecules in one run. Multiple RNA targets share the same limit; two 90-nt RNAs produce 120 windows and can be submitted with up to 2,000 molecules.

Results

SMRTnet returns one representative row per original RNA-compound pair, sorted by predicted binding probability. For targets longer than 31 nucleotides, SMRTnet evaluates overlapping windows and reports one of them. For an RNA with fewer than 40 windows (shorter than 70 nucleotides), it reports the highest-scoring window among those scoring at least 0.5. For longer RNAs, only windows inside a run of four or more consecutive windows scoring at least 0.5 qualify, so an isolated high-scoring window is not reported. When no window qualifies, SMRTnet reports the pair's lowest-scoring window, so a No row shows the weakest window rather than the best one. The selected window is included so the score remains traceable to the exact model input.

SMRTnet groups results by RNA name and molecule name, so give every RNA and every molecule its own name. Rows that share a name are merged into a single result row.

The output table is downloadable and copyable for follow-up triage. The ProteinIQ tool focuses on binding prediction and ranked screening results; it does not support SMRTnet's separate attention-based binding site interpretation workflow.

Interpreting SMRTnet results

The binding probability is a model score, not a dissociation constant. A score of 0.82 means the ensemble strongly classifies the pair as an interaction relative to the training distribution. It does not mean 82 percent occupancy, 82 percent experimental success, or a specific $K_d$ value.

Score differences matter most near the top of a screen. For example, a set of natural products scoring 0.91, 0.88, and 0.86 against the same RNA should generally be treated as a top tier rather than as three precisely separated affinities. Conversely, a compound scoring 0.62 against one RNA and 0.18 against closely related decoy RNAs is more interesting than the same 0.62 score without selectivity context.

Secondary structure quality strongly affects interpretation. A structure supported by SHAPE-MaP, DMS probing, enzymatic probing, or a conserved motif model carries more weight than a single minimum-free-energy fold. For secondary structure prediction before screening, ViennaRNA can help generate dot-bracket hypotheses, but computational folds should be treated as hypotheses rather than confirmed binding-ready structures.

How SMRTnet works

SMRTnet is an open-source deep learning method from the Zhang lab. ProteinIQ runs the published SMRTnet inference workflow rather than reimplementing the model.

The model uses four main representations:

• RNA sequence representation: RNASwan-seq, an RNA language model with transformer encoder blocks and rotary positional embeddings, learns sequence-level features from RNA tokens.
• RNA structure representation: A convolutional block reads dot-bracket secondary structure and extracts local pairing, loop, and stem-pattern features.
• Molecule language representation: MoLFormer converts the SMILES string into a learned chemical embedding.
• Molecule graph representation: A graph attention network represents the compound as atoms and bonds, then learns attention-weighted molecular features.

An attention-based multimodal fusion module combines RNA and molecule features before classification. For inference, SMRTnet scores every window with five models from 5-fold cross-validation and takes the median of their five probabilities. ProteinIQ reports that median and applies SMRTnet's greater-than-0.5 interaction rule.

The original study evaluated SMRTnet on small molecule-RNA interaction benchmarks including R-BIND, R-SIM, SMMRNA, NALDB, and a NewPub set. The authors also tested predictions experimentally across 10 disease-associated RNA targets, including mRNAs of hard-to-drug proteins, onco-miRNAs, viral RNAs, and RNA repeat expansions. Forty hits were confirmed by microscale thermophoresis with nanomolar-to-micromolar dissociation constants, and one MYC IRES-associated compound showed downstream cellular effects in cancer cell lines.

When to use SMRTnet vs alternatives

SMRTnet is best for ligand-first or target-first screening against RNA when the available structural evidence is secondary structure. It is not a replacement for RNA-ligand docking when a high-quality 3D RNA structure and binding site are available.

A practical RNA-targeting workflow often starts with structure evidence, then screening, then validation. For example, a MYC IRES or viral stem-loop can be folded or constrained with experimental probing data, screened with SMRTnet, then followed by orthogonal assays on top-ranked molecules. If a candidate affects protein expression or viral replication, additional controls are needed to distinguish direct RNA binding from indirect cellular effects.

Limitations

• No binding pose: SMRTnet predicts interaction probability. It does not return a 3D RNA-ligand complex, docking pose, or atomic contact map in the ProteinIQ implementation.
• No affinity unit: Scores are not $K_d$, IC50, or binding free energy. Experimental binding strength still needs measurement.
• Secondary structure dependence: Incorrect dot-bracket structures can move the model away from the biological RNA conformation of interest.
• Training distribution effects: Unusual chemotypes, modified nucleotides, protein-bound RNA conformations, and rare RNA motifs may score less reliably if similar examples were sparse in training data.
• Single-threshold classification: Interaction is positive only above 0.5. For real screening campaigns, ranking, replicate evidence, chemical tractability, and target selectivity usually matter more than a single yes/no label.
